2M DVRs installation guide

2M DVRs installation guide, 2M Technology Inc. is a leading provider of complete end to end low voltage Audio Video solutions to the homeland security, institutional and commercial market segments. The company offers a full suite of integrated intrusion, video and audio security solutions.

How to Access Device from Web 2M DVRs

When devices are connected to the network, they can also be accessible from a computer. The first thing you need to make sure of is that the computer you are using and the DVR/NVR are connected to the same network (network is coming from the same router for both devices). You will first need to obtain the IP address of the DVR/NVR from Menu → System → Network → IPv4 address.

After noting the IP address of your device, open Internet Explorer and in the address search bar type in the DVR/NVR IP address. If the NVR and the computer are on the same network then it will pull up the login page of the DVR/NVR. The credentials will be the same as when you log into the local interface of your device.

image 38

Read Next :

  1. Resetting your UNV NVR Password 3 Ways
  2. Lorex Fusion Setup Guide
  3. Hikvision AX PRO Configuration Full Setup – Video

How to Find the Serial Number Using 2M Tool

Click here to download 2M Tool

2M Tool is used to find the IP address of your 2M NVR, DVR, or IP camera, as well as limited management of its settings. You only need to make sure that the computer you are using 2M Tool on is connected to the same network as the device that you are trying to search for.

Why do we need the serial number? The serial number is mainly used in case of a customer needing a password reset on their device.

How do we find the serial number? There are a few ways to find the number:

  • sticker on the device
  • sticker on the box that the device came in
  • web page client of the device
  • using 2M Tool

In the case that you forget the password for you device in which you will not be able to access the web page, and the camera is too high up to reach to find the sticker, you can use 2M Tool to find the serial number. 2M Tool does not automatically show the number; you must force it to show. First, you will need to click on the Settings icon to show the options:


Then another window will open where you can select Serial Number to show.


Once you hit OK, the serial number will then appear.

How to Install Plugin for Internet Explorer
